 Topic: Small engine question
Posted: 03 Nov 2020 at 5:20pm |
|
I have an Ariens hedge trimmer, I think is manufactured by Tanaka, problem no fire to spark plug. Have disconnected the wire to stop switch, still no fire. Was going to check points ...No points.. checked the coil where stop wire is connected to coil, shows grounded to laminated iron core. I think the coil has an electronic ignition integral to the coil. Am I checking correct, and does the continuity from stop switch wire terminal to ground indicate a bad coil? Thanks, Tim
|
 |
|
Sponsored Links
|
|
|
Dave H
Orange Level
Joined: 11 Sep 2009
Location: Central IL
Points: 3482
|
Post Options
Thanks(0)
Quote Reply
Posted: 03 Nov 2020 at 5:54pm |
|
I would say that you have a bad ignition module.
|
|
steve(ill)
Orange Level Access
Joined: 11 Sep 2009
Location: illinois
Points: 77872
|
Post Options
Thanks(0)
Quote Reply
Posted: 03 Nov 2020 at 6:02pm |
I agree with DAVE... Problem is probably the "internal point / condenser" type thingy... Here is a CHEAP drawing of the old systems... Note that one side of the coils is GROUNDED so , YEA, your kill wire would show continuity to ground when disconnected from the switch... I dont think that is the problem... but EVERYTHING is one piece anyway.
Edited by steve(ill) - 03 Nov 2020 at 6:04pm
|
|
Like them all, but love the "B"s.
|
|
TMiller/NC
Orange Level Access
Joined: 11 Sep 2009
Location: Lenoir, NC
Points: 1774
|
Post Options
Thanks(0)
Quote Reply
Posted: 03 Nov 2020 at 6:11pm |
Thanks for the replies, I kind of thought module might be bad, so looked for one online, the Tanaka parts said wasn't ordered often and should call or email for them to check stock. Thanks, Tim
|
|
Hubert (Ga)engine7
Orange Level
Joined: 12 Sep 2009
Location: Jackson Cnty,GA
Points: 6128
|
Post Options
Thanks(0)
Quote Reply
Posted: 03 Nov 2020 at 7:06pm |
|
You might be able to buy a Bauer battery powered trimmer from Horrible Fright for what that ignition module costs. Just a thought. Hate to promote that chinese stuff but Bauer seems to have some good products. I bought one for my bride and she likes it. I have one on a pole that fits on my Stihl power head that I use.
|
|
Just an old country boy saved by the grace of God.
|
|
ac fleet
Orange Level
Joined: 12 Jan 2014
Location: Arrowsmith, ILL
Points: 2211
|
Post Options
Thanks(0)
Quote Reply
Posted: 04 Nov 2020 at 7:09pm |
|
ignition module is dead! ---standard on the electronic modules on everything ---wish they still had points so you could work on them.
|
|
http://machinebuildersnetwork.com/
|
|
DMiller
Orange Level Access
Joined: 14 Sep 2009
Location: Hermann, Mo
Points: 29578
|
Post Options
Thanks(0)
Quote Reply
Posted: 05 Nov 2020 at 3:53am |
 ac fleet wrote:
ignition module is dead! ---standard on the electronic modules on everything ---wish they still had points so you could work on them.
|
Makes it too easy, anyone can then fix them.
|
|
Coke
Silver Level
Joined: 30 Sep 2018
Location: MIdwest
Points: 215
|
Post Options
Thanks(0)
Quote Reply
Posted: 05 Nov 2020 at 10:24am |
I thought all the smaller engines used capacitive discharge now? If you can't see an actual coil, could be that is what you have?
Edited by Coke - 05 Nov 2020 at 10:25am
|
|
1957 D17 Diesel w/ M&W Pistons
|
|
Stan IL&TN
Orange Level
Joined: 13 Sep 2009
Location: Elvis Land
Points: 6730
|
Post Options
Thanks(0)
Quote Reply
Posted: 05 Nov 2020 at 11:06am |
|
Had that happen to my Stihl chainsaw this summer. No spark even with kill wire removed. Ordered coil module and back in business.
|
|
1957 WD45 dad's first AC
1968 one-seventy
1956 F40 Ferguson
|
|
TMiller/NC
Orange Level Access
Joined: 11 Sep 2009
Location: Lenoir, NC
Points: 1774
|
Post Options
Thanks(0)
Quote Reply
Posted: 05 Nov 2020 at 6:44pm |
Update....after the comments, I decided to reinstall the module just to be sure. Used a folded paper to set gap at flywheel, was I surprised with a good spark. reassembled, cranked it up and cut for a couple minutes, stopped running, restarted after a few minutes repeated same, run die, finally the light came on....running out of gas, bought a new in tank fuel filter hasn't stopped since. Thanks for the response, Tim
|
|
