 Topic: rare 70-52 plow
Posted: 19 Oct 2019 at 7:09am |
OK, I've got my '70-53' plow almost all dissassembled which I'm converting into '52'. Silly question. Should the 'beam and blades' section U-bolted to the 'pipe' be able to rotate relative to the 'triangulare piece with the beaming screw ? Sorry for the non correct terms... Also shold the Snap-Coupler bar be centered between the 2 plows, it was(is) inline with the center plow of 3.
Thanks yeah you can laugh....
Jay
|
|
3 D-14s,A-C forklift, B-112
Kubota BX23S lil' TOOT( The Other Orange Tractor)
Never burn your bridges, unless you can walk on water
|
 |
|
Sponsored Links
|
|
|
jaybmiller
Orange Level Access
Joined: 12 Sep 2009
Location: Greensville,Ont
Points: 21460
|
Post Options
Thanks(0)
Quote Reply
Posted: 19 Oct 2019 at 8:55am |
hmm, I figure the collar between the uprights is the 'positioning adjustment device'...yeah the thing with a square headed set screw that's been rusted in place for 50 years or so ? THAT should be 'fun' to loosen and remove.. so far I've bused TWO 1/2" rachets getting things unstuck ! Jay
|
|
3 D-14s,A-C forklift, B-112
Kubota BX23S lil' TOOT( The Other Orange Tractor)
Never burn your bridges, unless you can walk on water
|
|
Gerald J.
Orange Level
Joined: 12 Sep 2009
Location: Hamilton Co, IA
Points: 5636
|
Post Options
Thanks(0)
Quote Reply
Posted: 19 Oct 2019 at 9:18am |
|
Laterally you want the left side of the right plow bottom to be inside the rear tractor wheel by the width of the plow bottom whether its 2 or 3 or 5 bottoms. So you keep the hitch the same, just remove the left bottom and its shank from the three bottom frame and hitch.
Gerald J.
|
|
jaybmiller
Orange Level Access
Joined: 12 Sep 2009
Location: Greensville,Ont
Points: 21460
|
Post Options
Thanks(0)
Quote Reply
Posted: 19 Oct 2019 at 11:11am |
so the 3 hour workout I got this morning I really didn't need ??? sigh... oh well... guess I'll see how humpty-dumpty goes back together..... heck, it's fun, warm-cool, sunny, quiet.... Thanks for the edumucation !
|
|
3 D-14s,A-C forklift, B-112
Kubota BX23S lil' TOOT( The Other Orange Tractor)
Never burn your bridges, unless you can walk on water
|
|
Dusty MI
Orange Level
Joined: 13 Sep 2009
Location: Charlotte, Mi
Points: 5053
|
Post Options
Thanks(0)
Quote Reply
Posted: 19 Oct 2019 at 12:04pm |
On our 3 bottom snap coupler plow we used on out late model WD, to change from 3 bottom to a 2 bottom, you removed the 2nd bottom and moved the 3rd to where the second was. This was because the third bottom had a much longed land-slide.
Dusty
|
|
917 H, '48 G, '65 D-10 series III "Allis Express"
|
|
Sugarmaker
Orange Level
Joined: 12 Jul 2013
Location: Albion PA
Points: 8167
|
Post Options
Thanks(0)
Quote Reply
Posted: 19 Oct 2019 at 2:22pm |
Jay, I made one old plow from two old plows. I went through some of the same frustrations. Trying to get parts freed up and working. I can tell you that if you want to plow with it, the time to fix it is worth it! Even hooking it up was nice because I could adjust the SC hitch on the plow up or down to back into the SC bell on the tractor. I think its time for some pictures! Regards, Chris
|
|
D17 1958 (NFE), WD45 1954 (NFE), WD 1952 (NFE), WD 1950 (WFE), Allis F-40 forklift, Allis CA, Allis D14, Ford Jubilee, Many IH Cub Cadets, 32 Ford Dump, 65 Comet.
|
|
Lars(wi)
Orange Level Access
Joined: 14 Sep 2009
Location: Permian Basin
Points: 6628
|
Post Options
Thanks(0)
Quote Reply
Posted: 19 Oct 2019 at 2:53pm |
|
make sure the tractor you use to plow with, you have the wheels set at the correct width.
|
|
I tried to follow the science, but it was not there. I then followed the money, and that’s where I found the science.
|
|
jaybmiller
Orange Level Access
Joined: 12 Sep 2009
Location: Greensville,Ont
Points: 21460
|
Post Options
Thanks(0)
Quote Reply
Posted: 19 Oct 2019 at 5:40pm |
Thanks for the comments guys ! I'm just trying to make a saleable 2F plow. After 1/2 day of heat and oil still can't get the beam to rotate on the big bar. Maybe the frost tonight will help ?? lol... At least it now LOOKS like a 2F plow !! I'm hoping it'll free up once it's back in the dirt, where it belongs. Cheers Jay
|
|
3 D-14s,A-C forklift, B-112
Kubota BX23S lil' TOOT( The Other Orange Tractor)
Never burn your bridges, unless you can walk on water
|
|
bigfish_Oh
Orange Level
Joined: 13 Sep 2009
Location: West Liberty,Oh
Points: 1226
|
Post Options
Thanks(0)
Quote Reply
Posted: 19 Oct 2019 at 6:36pm |
I've always said the difference between my plows and your real plow is my beaming screw works !
|
|
