 Topic: CA distributor/governor oil supply line.
Posted: 02 Oct 2018 at 8:36pm |
|
....I need to replace the oil line from the "T" at the head/rocker
supply to the "T" at the Governor oil supply on my CA. It is a very
small steel tubing with compression fittings on each end. I am hopping
this is something I can buy already made up...or at least steer me to a
supplier of the tubing and fittings.
|
 |
|
Sponsored Links
|
|
|
DSeries4
Orange Level
Joined: 12 Sep 2009
Location: Ontario, Canada
Points: 7445
|
Post Options
Thanks(1)
Quote Reply
Posted: 02 Oct 2018 at 8:52pm |
|
Napa. Use tube benders to shape it.
|
|
'49 G, '54 WD45, '55 CA, '56 WD45D, '57 WD45, '58 D14, '59 D14, '60 D14, '61 D15D, '66 D15II, '66 D21II, '67 D17IV, '67 D17IVD, '67 190XTD, '73 620, '76 185, '77 175, '84 8030, '85 6080
|
|
Shade Tree
Bronze Level
Joined: 17 Aug 2018
Location: Shiner,Texas
Points: 25
|
Post Options
Thanks(0)
Quote Reply
Posted: 02 Oct 2018 at 8:56pm |
...what size is the tubing that runs to the governor oil supply fitting,.?
|
|
pumpkinman
Orange Level
Joined: 20 Jul 2011
Location: S.E. Michigan
Points: 252
|
Post Options
Thanks(1)
Quote Reply
Posted: 02 Oct 2018 at 9:06pm |
I think I have one Will look tomarow in daylite will get back to you kent
|
|
Sugarmaker
Orange Level
Joined: 12 Jul 2013
Location: Albion PA
Points: 8434
|
Post Options
Thanks(1)
Quote Reply
Posted: 02 Oct 2018 at 10:12pm |
Yea I would also go to NAPA store with the old parts and match up the connections. Compression type fitting. Probably 1/8 inch steel line? They might have the new flexible brake line also. Might be easier to form? Regards, Chris
|
|
D17 1958 (NFE), WD45 1954 (NFE), WD 1952 (NFE), WD 1950 (WFE), Allis F-40 forklift, Allis CA, Allis D14, Ford Jubilee, Many IH Cub Cadets, 32 Ford Dump, 65 Comet.
|
|
Shade Tree
Bronze Level
Joined: 17 Aug 2018
Location: Shiner,Texas
Points: 25
|
Post Options
Thanks(0)
Quote Reply
Posted: 03 Oct 2018 at 7:44am |
|
...it appears mine rusted out...pretty strange, not much rust on the tractor and all the other small tubing lines are fine...it probably had impurities in the steel at the point it rusted out. Thanks for your attention.
|
|
CAL(KS)
Orange Level
Joined: 18 Sep 2009
Location: Chapman, KS
Points: 3793
|
Post Options
Thanks(1)
Quote Reply
Posted: 03 Oct 2018 at 8:40am |
|
1/8 inch compression. same size as oil pressure gauge line
Edited by CAL(KS) - 03 Oct 2018 at 8:41am
|
|
Me -C,U,UC,WC,WD45,190XT,TL-12,145T,HD6G,HD16,HD20
Dad- WD, D17D, D19D, RT100A, 7020, 7080,7580, 2-8550's, 2-S77, HD15
|
|
Shade Tree
Bronze Level
Joined: 17 Aug 2018
Location: Shiner,Texas
Points: 25
|
Post Options
Thanks(0)
Quote Reply
Posted: 03 Oct 2018 at 8:43am |
...thanks, going to town to find it.
|
|
Dakota Dave
Orange Level
Joined: 12 Sep 2009
Location: ND
Points: 3965
|
Post Options
Thanks(1)
Quote Reply
Posted: 03 Oct 2018 at 8:48am |
|
My C had 1/8" copper line on it since I bought it in 1986. I replaced the ring in the compression fitting when I linked it many years ago. It was the same ad the sending line on a shallow well pump.
|
|
