720 steering box

 Post Reply Post Reply
Author
Message
AC720Man View Drop Down
Orange Level
Orange Level
Avatar

Joined: 10 Oct 2016
Location: Shenandoah, Va
Points: 4605
Post Options Post Options   Thanks (0) Thanks(0)   Quote AC720Man Quote  Post ReplyReply Direct Link To This Post Topic: 720 steering box
    Posted: 19 Jun 2019 at 12:52pm
Having an issue with my steering on one of my 720’s. Seams like a lot of play and I am always correcting left to right to go straight. Sometimes it locks if I steer all the way left. A hard pull the the right of the steering wheel will get it back but this seams to be getting worse. Anyone had this issue and if so are there adjustments to make or just have to replace it?
1968 B-208, 1976 720 (2 of them)Danco brush hog, single bottom plow,52" snow thrower, belly mower,rear tine tiller, rear blade, front blade, 57"sickle bar,1983 917 hydro, 1968 7hp sno-bee, 1968 190XTD
Back to Top
Sponsored Links


Back to Top
Dusty MI View Drop Down
Orange Level
Orange Level
Avatar

Joined: 13 Sep 2009
Location: Charlotte, Mi
Points: 5050
Post Options Post Options   Thanks (0) Thanks(0)   Quote Dusty MI Quote  Post ReplyReply Direct Link To This Post Posted: 19 Jun 2019 at 8:21pm
I have a loader on my 720. I've only had it for a few years. Anyway a couple of years ago it stopped steering, the steering wheel turned but had no control.
Some where I learned that a steering gear box from a Chevy, Vega I think, would fit, so I put one in.
I'm rather to say this but after I had my 720 all back together it still would not steer. A nub inside the steering wheel had sheered off, I fixed that and now the 720 pulled to the left.

Dusty
917 H, '48 G, '65 D-10 series III "Allis Express"
Back to Top
Charlie175 View Drop Down
Orange Level
Orange Level


Joined: 11 Sep 2009
Location: Shenandoah, VA
Points: 6351
Post Options Post Options   Thanks (0) Thanks(0)   Quote Charlie175 Quote  Post ReplyReply Direct Link To This Post Posted: 20 Jun 2019 at 6:08am
Didn't they use a Chevy Vega Steering box or close to it? Seems I remember reading that somewhere
Charlie

'48 B, '51 CA, '56 WD45 '61 D17, '63 D12, '65 D10 , '68 One-Ninety XTD
Back to Top
Charlie175 View Drop Down
Orange Level
Orange Level


Joined: 11 Sep 2009
Location: Shenandoah, VA
Points: 6351
Post Options Post Options   Thanks (0) Thanks(0)   Quote Charlie175 Quote  Post ReplyReply Direct Link To This Post Posted: 20 Jun 2019 at 6:13am
Charlie

'48 B, '51 CA, '56 WD45 '61 D17, '63 D12, '65 D10 , '68 One-Ninety XTD
Back to Top
Steve in NJ View Drop Down
Orange Level Access
Orange Level Access
Avatar

Joined: 12 Sep 2009
Location: Andover, NJ
Points: 11503
Post Options Post Options   Thanks (0) Thanks(0)   Quote Steve in NJ Quote  Post ReplyReply Direct Link To This Post Posted: 20 Jun 2019 at 6:37am
Talk to Mike Noonan about that. (He may even see this post. ) I think Mike Brown has a replacement steering setup for the 616-720 machines. Seems like when they have a loader on them, the extra weight is just a bit much for the stock steering box......
Steve@B&B
39'RC, 43'WC, 48'B, 49'G, 50'WF, 65 Big 10, 67'B-110, 75'716H, 2-620's, & a Motorhead wife
Back to Top
AC720Man View Drop Down
Orange Level
Orange Level
Avatar

Joined: 10 Oct 2016
Location: Shenandoah, Va
Points: 4605
Post Options Post Options   Thanks (0) Thanks(0)   Quote AC720Man Quote  Post ReplyReply Direct Link To This Post Posted: 20 Jun 2019 at 7:46pm
I was looking in my repair manual, quite a chore to disassemble so I better wait until late fall to start this project. I use it too much to have it down for that amount of work. I remember when I disassembled the tractor to restore it of what a massive amount of parts there are. I stripped it to the bare frame. That was 8 years ago.
I believe I had heard before that a Vega steering box may work.
1968 B-208, 1976 720 (2 of them)Danco brush hog, single bottom plow,52" snow thrower, belly mower,rear tine tiller, rear blade, front blade, 57"sickle bar,1983 917 hydro, 1968 7hp sno-bee, 1968 190XTD
Back to Top
Steve in NJ View Drop Down
Orange Level Access
Orange Level Access
Avatar

Joined: 12 Sep 2009
Location: Andover, NJ
Points: 11503
Post Options Post Options   Thanks (0) Thanks(0)   Quote Steve in NJ Quote  Post ReplyReply Direct Link To This Post Posted: 25 Jun 2019 at 6:35am
I know the feeling. Stripped my 620 down to the bare frame 4 years ago or more, and it still isn't running yet. Got 90% of it together. Hope to fire the engine this summer. I believe the Vega/Monza power box is the ticket for easier steering in a 616-720...
Mike Brown is the guy to get a hold of. He's Mike Noonan's friend.
Steve@B&B
39'RC, 43'WC, 48'B, 49'G, 50'WF, 65 Big 10, 67'B-110, 75'716H, 2-620's, & a Motorhead wife
Back to Top
mnoonan-NEWI View Drop Down
Orange Level
Orange Level
Avatar

Joined: 11 Sep 2009
Location: Marinette, WI
Points: 738
Post Options Post Options   Thanks (0) Thanks(0)   Quote mnoonan-NEWI Quote  Post ReplyReply Direct Link To This Post Posted: 25 Jun 2019 at 8:31pm
Originally posted by AC720Man AC720Man wrote:

Having an issue with my steering on one of my 720’s. Seams like a lot of play and I am always correcting left to right to go straight. Sometimes it locks if I steer all the way left. A hard pull the the right of the steering wheel will get it back but this seams to be getting worse. Anyone had this issue and if so are there adjustments to make or just have to replace it?

The GM 605 power steering box is maybe the best choice or maybe an orbital valve with a remote cylinder from a John Deere 318 or similar or a Simplicity Sunstar tractor would work for you. I would not recomend the Vega power steering unit that I used. I doesn't perform well with only a 13/1 steering ratio. The GM 605 I believe has a 20/1 ratio. Mike


Edited by mnoonan-NEWI - 25 Jun 2019 at 8:32pm
AC CA, Ferguson TO-20, Ford NAA, M-M BG, AC #3 Mower, SC Plow, PH Digger, AC 720's with Ark 700 loader & Brantly Backhoe, "Mini B" w/flathead Ford V8
Back to Top
AC720Man View Drop Down
Orange Level
Orange Level
Avatar

Joined: 10 Oct 2016
Location: Shenandoah, Va
Points: 4605
Post Options Post Options   Thanks (0) Thanks(0)   Quote AC720Man Quote  Post ReplyReply Direct Link To This Post Posted: 25 Jun 2019 at 9:22pm
Oh so we are talking about power steering? Interesting, tell me more about the connections and power source.
1968 B-208, 1976 720 (2 of them)Danco brush hog, single bottom plow,52" snow thrower, belly mower,rear tine tiller, rear blade, front blade, 57"sickle bar,1983 917 hydro, 1968 7hp sno-bee, 1968 190XTD
Back to Top
mnoonan-NEWI View Drop Down
Orange Level
Orange Level
Avatar

Joined: 11 Sep 2009
Location: Marinette, WI
Points: 738
Post Options Post Options   Thanks (0) Thanks(0)   Quote mnoonan-NEWI Quote  Post ReplyReply Direct Link To This Post Posted: 25 Jun 2019 at 10:40pm
Originally posted by AC720Man AC720Man wrote:

Oh so we are talking about power steering? Interesting, tell me more about the connections and power source.

From charge pump into power steering box then out to the hydraulic control valve. Need to remove steering box mounting plate and move back about 5/8".

If you're looking for a manual steering box, I have my old one I would sell.
Thanks, Mike
AC CA, Ferguson TO-20, Ford NAA, M-M BG, AC #3 Mower, SC Plow, PH Digger, AC 720's with Ark 700 loader & Brantly Backhoe, "Mini B" w/flathead Ford V8
Back to Top
AC720Man View Drop Down
Orange Level
Orange Level
Avatar

Joined: 10 Oct 2016
Location: Shenandoah, Va
Points: 4605
Post Options Post Options   Thanks (0) Thanks(0)   Quote AC720Man Quote  Post ReplyReply Direct Link To This Post Posted: 30 Jun 2019 at 8:18pm
Did some checking on my front end to figure out why I had so much play. Previous owner had used the incorrect bushing and bolt. Also the nut in the axle was messed up. Had to go to a 3/4” bolt. Luckily local hardware store had a bushing that fit perfect. Ran a 3/4x10 tap in to the brass nut. Nice fit and now the slop is gone. Also helped my steering a great deal.
1968 B-208, 1976 720 (2 of them)Danco brush hog, single bottom plow,52" snow thrower, belly mower,rear tine tiller, rear blade, front blade, 57"sickle bar,1983 917 hydro, 1968 7hp sno-bee, 1968 190XTD
