6060 PTO housing vs. A 6080

 Post Reply Post Reply
Author
Message
allis6080 View Drop Down
Silver Level
Silver Level
Avatar

Joined: 19 Jan 2011
Location: erie Pa
Points: 334
Post Options Post Options   Thanks (0) Thanks(0)   Quote allis6080 Quote  Post ReplyReply Direct Link To This Post Topic: 6060 PTO housing vs. A 6080
    Posted: 26 Apr 2020 at 6:51pm
So I was pulling my truck and trailer out of the wet yard with my 6060 put chain around the draw bar carrier and well need less to say it pulled the bolts out of the PTO housing instead of pulling my truck and trailer. So my question is will a 6080 PTO housing swap easily to the 6060? I have a 6080 parts tractor out back. Thanks for any help or info.

Edited by allis6080 - 27 Apr 2020 at 5:21am
6060 s\n 5016

1947 JD B
Back to Top
Sponsored Links


Back to Top
DSeries4 View Drop Down
Orange Level
Orange Level
Avatar

Joined: 12 Sep 2009
Location: Ontario, Canada
Points: 7483
Post Options Post Options   Thanks (0) Thanks(0)   Quote DSeries4 Quote  Post ReplyReply Direct Link To This Post Posted: 26 Apr 2020 at 9:26pm
Another hard lesson learned that a drawbar carrier is NOT a pull point.  It holds the drawbar up, that's it.   That's why I keep a clevis in the tool box.
I do not think the 6080 rear end is the same.  These 2 tractors used transmissions and rear ends from 2 separate Fiat models.  One was 8 speed and one was 12 speed as well.
'49 G, '54 WD45, '55 CA, '56 WD45D, '57 WD45, '58 D14, '59 D14, '60 D14, '61 D15D, '66 D15II, '66 D21II, '67 D17IV, '67 D17IVD, '67 190XTD, '73 620, '76 185, '77 175, '84 8030, '85 6080
Back to Top
allis6080 View Drop Down
Silver Level
Silver Level
Avatar

Joined: 19 Jan 2011
Location: erie Pa
Points: 334
Post Options Post Options   Thanks (0) Thanks(0)   Quote allis6080 Quote  Post ReplyReply Direct Link To This Post Posted: 27 Apr 2020 at 5:20am
Yeah definitely a hard lesson. I'm going to make some calls today and see if I can get a used housing. My luck it will cost a fortune.
6060 s\n 5016

1947 JD B
Back to Top
allisrutledge View Drop Down
Orange Level
Orange Level


Joined: 30 Mar 2010
Location: SurgoinsvilleTN
Points: 1360
Post Options Post Options   Thanks (0) Thanks(0)   Quote allisrutledge Quote  Post ReplyReply Direct Link To This Post Posted: 27 Apr 2020 at 7:20am
I put one on mine last winter, was broke when I got it and I got tired of constantly worrying about it. I ordered it from someone in OH I think. I do remember it has 6070 on it with a paint marker. I don't know if that's correct but it fit. I also machined some rings and pressed them over the round nubs where the hitch bolts to reinforce it some. Mine was broke out at the bottom like it was overloaded? I'll see if I got a picture
Back to Top
allisrutledge View Drop Down
Orange Level
Orange Level


Joined: 30 Mar 2010
Location: SurgoinsvilleTN
Points: 1360
Post Options Post Options   Thanks (0) Thanks(0)   Quote allisrutledge Quote  Post ReplyReply Direct Link To This Post Posted: 27 Apr 2020 at 7:55am
Allis Chalmers still exist in my mind and barns
Back to Top
TramwayGuy View Drop Down
Orange Level Access
Orange Level Access


Joined: 19 Jan 2010
Location: Northern NY
Points: 11718
Post Options Post Options   Thanks (0) Thanks(0)   Quote TramwayGuy Quote  Post ReplyReply Direct Link To This Post Posted: 27 Apr 2020 at 9:15am
Parts books show the rear housings are indeed different. Can you heli-coil the holes?
Back to Top
allis6080 View Drop Down
Silver Level
Silver Level
Avatar

Joined: 19 Jan 2011
Location: erie Pa
Points: 334
Post Options Post Options   Thanks (0) Thanks(0)   Quote allis6080 Quote  Post ReplyReply Direct Link To This Post Posted: 27 Apr 2020 at 9:20am
I still need to look at it a little more yet I have a machinist friend that may be able to re machine the holes
6060 s\n 5016

1947 JD B
Back to Top
allisrutledge View Drop Down
Orange Level
Orange Level


Joined: 30 Mar 2010
Location: SurgoinsvilleTN
Points: 1360
Post Options Post Options   Thanks (0) Thanks(0)   Quote allisrutledge Quote  Post ReplyReply Direct Link To This Post Posted: 27 Apr 2020 at 9:25am
By the way that is metric bolts, I think m20x2.5 pitch. I can look on my receipt from McMaster Carr if needed.
Allis Chalmers still exist in my mind and barns
Back to Top
allis6080 View Drop Down
Silver Level
Silver Level
Avatar

Joined: 19 Jan 2011
Location: erie Pa
Points: 334
Post Options Post Options   Thanks (0) Thanks(0)   Quote allis6080 Quote  Post ReplyReply Direct Link To This Post Posted: 27 Apr 2020 at 9:36am
Brenda from Sandy lake implement said m18x1.50x 130 bolts
6060 s\n 5016

1947 JD B
Back to Top
allis6080 View Drop Down
Silver Level
Silver Level
Avatar

Joined: 19 Jan 2011
Location: erie Pa
Points: 334
Post Options Post Options   Thanks (0) Thanks(0)   Quote allis6080 Quote  Post ReplyReply Direct Link To This Post Posted: 27 Apr 2020 at 9:37am
Thanks
6060 s\n 5016

1947 JD B
Back to Top
allisrutledge View Drop Down
Orange Level
Orange Level


Joined: 30 Mar 2010
Location: SurgoinsvilleTN
Points: 1360
Post Options Post Options   Thanks (0) Thanks(0)   Quote allisrutledge Quote  Post ReplyReply Direct Link To This Post Posted: 27 Apr 2020 at 9:38am
18 is correct
Allis Chalmers still exist in my mind and barns
Back to Top
wekracer View Drop Down
Orange Level
Orange Level
Avatar

Joined: 13 Oct 2009
Location: Tebbetts, MO
Points: 1590
Post Options Post Options   Thanks (0) Thanks(0)   Quote wekracer Quote  Post ReplyReply Direct Link To This Post Posted: 28 Apr 2020 at 8:27am
Someone told me a while back that they could be tapped to 3/4 if I remember correctly. Don’t remember if it was fine or coarse thread.
Back to Top
allisrutledge View Drop Down
Orange Level
Orange Level


Joined: 30 Mar 2010
Location: SurgoinsvilleTN
Points: 1360
Post Options Post Options   Thanks (0) Thanks(0)   Quote allisrutledge Quote  Post ReplyReply Direct Link To This Post Posted: 28 Apr 2020 at 9:36am
Taping to 3/4-16 would work if drilled to 11/16 .687 and its stripped and not broke out. M18 drill to tap is a little smaller
Allis Chalmers still exist in my mind and barns
Back to Top
allis6080 View Drop Down
Silver Level
Silver Level
Avatar

Joined: 19 Jan 2011
Location: erie Pa
Points: 334
Post Options Post Options   Thanks (0) Thanks(0)   Quote allis6080 Quote  Post ReplyReply Direct Link To This Post Posted: 30 Apr 2020 at 6:48pm
Originally posted by allisrutledge allisrutledge wrote:

Taping to 3/4-16 would work if drilled to 11/16 .687 and its stripped and not broke out. M18 drill to tap is a little smaller


You guys are right my buddy is going to drill and tap them for me. Thanks for all the replies.
6060 s\n 5016

1947 JD B
Back to Top
allisrutledge View Drop Down
Orange Level
Orange Level


Joined: 30 Mar 2010
Location: SurgoinsvilleTN
Points: 1360
Post Options Post Options   Thanks (0) Thanks(0)   Quote allisrutledge Quote  Post ReplyReply Direct Link To This Post Posted: 01 May 2020 at 7:01am
Great they were not busted, mine was broke out beyond reasonable repair due to some kind of rough treatment by previous owner. I nursed it as long as I could and then replaced it. Scott
Back to Top
