One-Ninety Belt Pulley
 Post Reply Post Reply
Author
Message
  Topic Search Topic Search  Topic Options Topic Options
JimWenigOH View Drop Down
Orange Level
Orange Level


Joined: 12 Sep 2009
Location: NC Ohio
Points: 1169 		Post Options Post Options   Thanks (0) Thanks(0)   Quote JimWenigOH Quote  Post ReplyReply Direct Link To This Post Topic: One-Ninety Belt Pulley
    Posted: 01 Dec 2020 at 5:18pm
I recently bought a 190XT with the belt pulley on it. I've been told the 190 was the last tractor model with this as an option. A few questions.  1. How many 190's do you know of that has a belt pulley ON THE TRACTOR?    2. Out of 1000 One-Ninety tractors produced, how many would you guess had this option on it?  The WD Series, you could take the belt pulley off one tractor and mount on another easily.   3.  Do all the 190 Series have the internal gear and shift collar etc. installed at the factory so you can just mount the pulley assembly and go? Maybe someone has a tractor opened up where you could take a look see. I was thinking that with the few tractors getting the pulley, that A-C would have saved the money and only installed the internals as required.
Back to Top
Sponsored Links


Back to Top
Leon B MO View Drop Down
Orange Level
Orange Level


Joined: 12 Sep 2009
Location: Old Monroe, Mo
Points: 2180 		Post Options Post Options   Thanks (0) Thanks(0)   Quote Leon B MO Quote  Post ReplyReply Direct Link To This Post Posted: 01 Dec 2020 at 5:52pm
At one point AC or an aftermarket company used the belt drive hole to run the ac compressors for the cab tractors. I thought the 175 still had the hole in the torque tube but used it to drive hyd pump.
Leon B
Uncle always said "Fill the back of the shovel and the front will take care of itself".
Back to Top
Joe(OH) View Drop Down
Orange Level
Orange Level
Avatar

Joined: 11 Sep 2009
Location: Montezuma, Ohio
Points: 991 		Post Options Post Options   Thanks (0) Thanks(0)   Quote Joe(OH) Quote  Post ReplyReply Direct Link To This Post Posted: 01 Dec 2020 at 6:57pm
I have a One Ninety XT diesel with factory belt pulley.
Life is simpler when you plow around the stump.
Back to Top
DougG View Drop Down
Orange Level
Orange Level


Joined: 20 Sep 2009
Location: Mo
Points: 8278 		Post Options Post Options   Thanks (0) Thanks(0)   Quote DougG Quote  Post ReplyReply Direct Link To This Post Posted: 01 Dec 2020 at 7:09pm
Do they work ? How do they engage ?
Back to Top
JimWenigOH View Drop Down
Orange Level
Orange Level


Joined: 12 Sep 2009
Location: NC Ohio
Points: 1169 		Post Options Post Options   Thanks (0) Thanks(0)   Quote JimWenigOH Quote  Post ReplyReply Direct Link To This Post Posted: 01 Dec 2020 at 8:11pm
Originally posted by DougG DougG wrote:

Do they work ? How do they engage ?


The tractor I just bought has engine problems and doesn't run. I was planning on putting the belt pulley on another XT I have. The control knob is located above the brake pedals through the firewall.
Back to Top
Adam Stratton View Drop Down
Orange Level Access
Orange Level Access


Joined: 11 Sep 2009
Location: SW MO
Points: 1363 		Post Options Post Options   Thanks (0) Thanks(0)   Quote Adam Stratton Quote  Post ReplyReply Direct Link To This Post Posted: 01 Dec 2020 at 8:44pm
I had a gas xt that had been sitting quite a while. It had the lever to engage, but no linkage to it. I put a d series belt pulley on it and spun it with my 45 to get it limbered up and going again. Worked just fine.
Back to Top
MACK View Drop Down
Orange Level
Orange Level


Joined: 17 Nov 2009
Points: 7664 		Post Options Post Options   Thanks (0) Thanks(0)   Quote MACK Quote  Post ReplyReply Direct Link To This Post Posted: 01 Dec 2020 at 8:54pm
All 190 and it's had the gear in side. Don't think any 200s had it. I use my belt drive with a different pulley to drive my sprayer pump.         MACK
Back to Top
Fred in Pa View Drop Down
Orange Level
Orange Level
Avatar

Joined: 13 Sep 2009
Location: Hanover Pa.
Points: 9210 		Post Options Post Options   Thanks (0) Thanks(0)   Quote Fred in Pa Quote  Post ReplyReply Direct Link To This Post Posted: 01 Dec 2020 at 9:11pm
flat Belt pulley is same .  Assembly is not as Dseries said below .

Edited by Fred in Pa - 02 Dec 2020 at 5:29am
He who dies with the most toys is,
nonetheless ,still dead.
If all else fails ,Read all that is PRINTED.
Back to Top
DSeries4 View Drop Down
Orange Level
Orange Level
Avatar

Joined: 12 Sep 2009
Location: Ontario, Canada
Points: 7459 		Post Options Post Options   Thanks (0) Thanks(0)   Quote DSeries4 Quote  Post ReplyReply Direct Link To This Post Posted: 01 Dec 2020 at 9:21pm
The local tractor boneyard close to me has a couple of 190s with belt pulleys on them.  I think the assemblies are longer on them in order for the belt to clear the sheet metal at the front.
'49 G, '54 WD45, '55 CA, '56 WD45D, '57 WD45, '58 D14, '59 D14, '60 D14, '61 D15D, '66 D15II, '66 D21II, '67 D17IV, '67 D17IVD, '67 190XTD, '73 620, '76 185, '77 175, '84 8030, '85 6080
Back to Top
JimWenigOH View Drop Down
Orange Level
Orange Level


Joined: 12 Sep 2009
Location: NC Ohio
Points: 1169 		Post Options Post Options   Thanks (0) Thanks(0)   Quote JimWenigOH Quote  Post ReplyReply Direct Link To This Post Posted: 02 Dec 2020 at 7:51pm
Originally posted by MACK MACK wrote:

All 190 and it's had the gear in side. Don't think any 200s had it. I use my belt drive with a different pulley to drive my sprayer pump.         MACK

That's pretty much what I had in mind. Any idea what the shaft rpm is on it?
Back to Top
MACK View Drop Down
Orange Level
Orange Level


Joined: 17 Nov 2009
Points: 7664 		Post Options Post Options   Thanks (0) Thanks(0)   Quote MACK Quote  Post ReplyReply Direct Link To This Post Posted: 03 Dec 2020 at 6:04am
Don't remember the RPMs, but I think around 1250 RPMs. I believe it is in owners manual .                  MACK
Back to Top
Calvin Schmidt View Drop Down
Orange Level
Orange Level
Avatar

Joined: 11 Sep 2009
Location: Ontario Can.
Points: 4530 		Post Options Post Options   Thanks (0) Thanks(0)   Quote Calvin Schmidt Quote  Post ReplyReply Direct Link To This Post Posted: 03 Dec 2020 at 7:52am
I have a OneNiney gas with a pulley and a friend has a XT gas with a pulley. Both were the only ones sold new by the dealer. Yes the D series pulley will work but the OneNiney casting is longer for the belt to clear the rad.
Nothing is impossible if it is properly financed
Back to Top
Ross D. View Drop Down
Silver Level
Silver Level
Avatar

Joined: 02 Sep 2013
Location: Erin, Ont.
Points: 339 		Post Options Post Options   Thanks (0) Thanks(0)   Quote Ross D. Quote  Post ReplyReply Direct Link To This Post Posted: 04 Dec 2020 at 1:53pm

   Mack and Jim.   The pulley appears to be 1633 RPM with the engine at 2200
RPM's.       Ross D.
Back to Top
JimWenigOH View Drop Down
Orange Level
Orange Level


Joined: 12 Sep 2009
Location: NC Ohio
Points: 1169 		Post Options Post Options   Thanks (0) Thanks(0)   Quote JimWenigOH Quote  Post ReplyReply Direct Link To This Post Posted: 05 Dec 2020 at 8:40pm
Thanks for the info Ross, where did you find it?
Back to Top
Eldon (WA) View Drop Down
Orange Level
Orange Level
Avatar

Joined: 11 Sep 2009
Location: Spokane, WA
Points: 7765 		Post Options Post Options   Thanks (0) Thanks(0)   Quote Eldon (WA) Quote  Post ReplyReply Direct Link To This Post Posted: 06 Dec 2020 at 10:41am
Originally posted by JimWenigOH JimWenigOH wrote:

I recently bought a 190XT with the belt pulley on it. I've been told the 190 was the last tractor model with this as an option. A few questions.  1. How many 190's do you know of that has a belt pulley ON THE TRACTOR?    2. Out of 1000 One-Ninety tractors produced, how many would you guess had this option on it?  The WD Series, you could take the belt pulley off one tractor and mount on another easily.   3.  Do all the 190 Series have the internal gear and shift collar etc. installed at the factory so you can just mount the pulley assembly and go? Maybe someone has a tractor opened up where you could take a look see. I was thinking that with the few tractors getting the pulley, that A-C would have saved the money and only installed the internals as required.

I have a 180 with a belt pulley, are they set up the same way?
ALLIS EXPRESS!
This year:
Back to Top
DrAllis View Drop Down
Orange Level Access
Orange Level Access


Joined: 12 Sep 2009
Points: 21557 		Post Options Post Options   Thanks (0) Thanks(0)   Quote DrAllis Quote  Post ReplyReply Direct Link To This Post Posted: 06 Dec 2020 at 11:54am
Should be the same as a One-Ninety.
Back to Top
JimWenigOH View Drop Down
Orange Level
Orange Level


Joined: 12 Sep 2009
Location: NC Ohio
Points: 1169 		Post Options Post Options   Thanks (0) Thanks(0)   Quote JimWenigOH Quote  Post ReplyReply Direct Link To This Post Posted: 06 Dec 2020 at 12:10pm
Well yesterday I pulled the belt pulley cover plate off, and as Mack stated, the necessary gear, shift collar etc. were in place. So all I have to do is get a new gasket and switch the assembly from one tractor to another, along with transferring the shift rods.

Eldon,
 AGCO Parts Book shows the internals and assembly to be the same on both 180 and 190 tractors.
Back to Top
Eldon (WA) View Drop Down
Orange Level
Orange Level
Avatar

Joined: 11 Sep 2009
Location: Spokane, WA
Points: 7765 		Post Options Post Options   Thanks (0) Thanks(0)   Quote Eldon (WA) Quote  Post ReplyReply Direct Link To This Post Posted: 06 Dec 2020 at 8:31pm
Originally posted by JimWenigOH JimWenigOH wrote:

Well yesterday I pulled the belt pulley cover plate off, and as Mack stated, the necessary gear, shift collar etc. were in place. So all I have to do is get a new gasket and switch the assembly from one tractor to another, along with transferring the shift rods.

Eldon,
 AGCO Parts Book shows the internals and assembly to be the same on both 180 and 190 tractors.
Thanks, good to know. I have had a few people wanting to buy it off of this parts tractor but did not want to have to ship the whole torque tube.....
ALLIS EXPRESS!
This year:
Back to Top
Ross D. View Drop Down
Silver Level
Silver Level
Avatar

Joined: 02 Sep 2013
Location: Erin, Ont.
Points: 339 		Post Options Post Options   Thanks (0) Thanks(0)   Quote Ross D. Quote  Post ReplyReply Direct Link To This Post Posted: 07 Dec 2020 at 10:51am
   Hi Jim.   I am having trouble uploading the pictures. Page B31 of the service manual shows the RPM's.     Ross D.





Back to Top
JimWenigOH View Drop Down
Orange Level
Orange Level


Joined: 12 Sep 2009
Location: NC Ohio
Points: 1169 		Post Options Post Options   Thanks (0) Thanks(0)   Quote JimWenigOH Quote  Post ReplyReply Direct Link To This Post Posted: 07 Dec 2020 at 11:07am
Thanks Ross, I didn't think to look there.
