d17 fluids? |
Post Reply |
Author | |
dt1050
Orange Level Joined: 05 Jul 2011 Location: central pa Points: 1078 |
Post Options
Thanks(0)
Posted: 09 Jan 2018 at 7:07am |
with the recent 0 - 15 below weather the tractor wouldn't start and when it was turning over (very slowly with a very good battery) the power director lever was moving back and forth about 2 inches? pulled the dipstick and what ever was in there wouldn't run down the dipstick, wasn't froze but was very thick. now that the weather is warmer I'm gonna try to get it fired up and change all the fluids. I've seen several differant posts and read what the manuals say, but was wondering what fluids ya use your d17? A few posts said to use hydro trans in everything...(but the radiator and engine...) that sure would make it simple for fluids. thanks dt.
|
|
Just cause it's orange don't make it a tractor, there's only one..Allis Chalmers
|
|
Sponsored Links | |
Tim (Cent.WI)
Orange Level Joined: 19 Sep 2009 Location: Stratford, WI Points: 214 |
Post Options
Thanks(0)
|
That is correct, uses a Hy/Tran equivalent to AC Power Fluid 821 in the trans and rear end.
|
|
dt1050
Orange Level Joined: 05 Jul 2011 Location: central pa Points: 1078 |
Post Options
Thanks(0)
|
how about the power director and psteering?
|
|
Just cause it's orange don't make it a tractor, there's only one..Allis Chalmers
|
|
DrAllis
Orange Level Access Joined: 12 Sep 2009 Points: 19478 |
Post Options
Thanks(0)
|
EVERYWHERE EXCEPT ENGINE AND RADIATOR.
|
|
old farmer
Silver Level Access Joined: 12 Oct 2011 Location: Sturgis, Mich Points: 341 |
Post Options
Thanks(0)
|
From what you said it sounds like you didn’t have the foot clutch disengaged because you said power director lever was moving. Make it easier starting regardless of temperature
|
|
Tim (Cent.WI)
Orange Level Joined: 19 Sep 2009 Location: Stratford, WI Points: 214 |
Post Options
Thanks(0)
|
Power director takes the hy tran 821, the power steering is supposed to take dexron ATF but the 821 would probably work there as well.
|
|
Pat the Plumber CIL
Orange Level Joined: 11 Sep 2009 Location: Springfield,Il Points: 4675 |
Post Options
Thanks(0)
|
In really cold weather ( below 20 ) I have a short board cut to length that fits between clutch pedal fully depressed and axel . I start tractor with board in place and let it run for a few minutes before slowly letting clutch out .Starts easier without moving all that cold "fluid"
|
|
You only need to know 3 things to be a plumber;Crap rolls down hill,Hot is on the left and Don't bite your fingernails
1964 D-17 SIV 3 Pt.WF,1964 D-15 Ser II 3pt.WF ,1960 D-17 SI NF,1956 WD 45 WF. |
|
MACK
Orange Level Joined: 17 Nov 2009 Points: 7664 |
Post Options
Thanks(1)
|
Be safe, set on seat to hold clutch down, then let out to start warming the rest of oil. Also wares throw out bearing and fingers. MACK
|
|
dt1050
Orange Level Joined: 05 Jul 2011 Location: central pa Points: 1078 |
Post Options
Thanks(0)
|
I don't have a seat to sit on. there is no original seat, there is one for the back hoe, but can't see how it will work for running the tractor. it's a work in progress...
|
|
Just cause it's orange don't make it a tractor, there's only one..Allis Chalmers
|
|
dt1050
Orange Level Joined: 05 Jul 2011 Location: central pa Points: 1078 |
Post Options
Thanks(0)
|
wow, that stuff was nasty!!! pulled the plub and about a teaspoon of water came out the nothing...next a big blob of ? came out, then the fluid, followed by more blobs.
|
|
Just cause it's orange don't make it a tractor, there's only one..Allis Chalmers
|
|
DrAllis
Orange Level Access Joined: 12 Sep 2009 Points: 19478 |
Post Options
Thanks(0)
|
Install 3 gallons of diesel fuel and let it run for a few minutes and drain it again.
|
|
dt1050
Orange Level Joined: 05 Jul 2011 Location: central pa Points: 1078 |
Post Options
Thanks(0)
|
there was a lot of nasty in were the hydraulic fluid goes....wow. rear/trans wasn't bad, but the hydro compartent was a mess!!!
|
|
Just cause it's orange don't make it a tractor, there's only one..Allis Chalmers
|
|
Ijos27
Bronze Level Joined: 30 Jun 2022 Location: Whitewright Points: 10 |
Post Options
Thanks(0)
|
Hello everyone, I recently bought a allis chalmers d17 tractor series 2. And the 2 disticks after the engine dipstick are showing low on fluids. I want to refill them but I am sort of confused because I asked 2 different tractor owners about the fluids and what to get and where to put them so I need you alls help if you can help. So there is a dip stick at the right side of the tractor and I thought that was for transmission fluid the large black cap after the engine dipstick. I need to know what goes in there 80w gear oil or is that for sae20 hydraulic fluid. Then I have another dipstick to the right side of the shifter it's showing low and need to know what to pour into that one? I can email pictures of dipsticks and where they are located on tractor.
Link below shows the pictues of dipsticks. Paste into your browser that link. Please private message me.your replies if you know what I need.thanks https://drive.google.com/drive/folders/15Q9S76O8b_PuI7v52NokFD-CE6RZEQlo Edited by Ijos27 - 30 Jun 2022 at 8:28pm |
|
steve(ill)
Orange Level Access Joined: 11 Sep 2009 Location: illinois Points: 77649 |
Post Options
Thanks(0)
|
are you going to just fill up, or are you going to drain and refill... Some use trans / hydraulic fluid in BOTH compartments... Some might have 80-90 gear lube in the transmission.. I would drain that and check before i added anything.
|
|
Like them all, but love the "B"s.
|
|
Ijos27
Bronze Level Joined: 30 Jun 2022 Location: Whitewright Points: 10 |
Post Options
Thanks(0)
|
Don't have enough fluids to drain and refill would be expensive so I'm just filling up to proper levels. Look at pictures please at the link.
|
|
steve(ill)
Orange Level Access Joined: 11 Sep 2009 Location: illinois Points: 77649 |
Post Options
Thanks(0)
|
thats my point... you better suck out a sample and check or drain it ( you can reuse)... but you should not mix 80-90 gear lube with transmission/ hyd fluid....
|
|
Like them all, but love the "B"s.
|
|
steve(ill)
Orange Level Access Joined: 11 Sep 2009 Location: illinois Points: 77649 |
Post Options
Thanks(0)
|
|
|
Like them all, but love the "B"s.
|
|
Ijos27
Bronze Level Joined: 30 Jun 2022 Location: Whitewright Points: 10 |
Post Options
Thanks(0)
|
Thank you all for the help
Edited by Ijos27 - 01 Jul 2022 at 7:38am |
|
Ijos27
Bronze Level Joined: 30 Jun 2022 Location: Whitewright Points: 10 |
Post Options
Thanks(0)
|
Thanks
Edited by Ijos27 - 01 Jul 2022 at 7:37am |
|
DrAllis
Orange Level Access Joined: 12 Sep 2009 Points: 19478 |
Post Options
Thanks(0)
|
Hydraulic fluid goes in the breather/dipstick on the right side under the fuel tank. Transmission oil into the breather/dipstick to the right of the gearshift. Transmission oil or hydraulic oil to the left and forward of the gearshift hex head dipstick.
|
|
Ijos27
Bronze Level Joined: 30 Jun 2022 Location: Whitewright Points: 10 |
Post Options
Thanks(0)
|
Dr. Allis. On the last sentence you said transmission or hydraulic fluid into left of gearshift forward hex head nut. What does that reservoir go to? I'd like to put proper fluids into it so if it goes to the transmission I'll put gear oil if it goes to hydraulic I'll put hydraulic fluid into it
|
|
DrAllis
Orange Level Access Joined: 12 Sep 2009 Points: 19478 |
Post Options
Thanks(0)
|
Series 3 and 4 D-17 that fill/check point is the HYDRAULIC system. If it is older than series 3 it is the power Director clutch and PTO gears, which will take abut any kind of oil. If changing it, use hyd/trans oil.
|
|
Ijos27
Bronze Level Joined: 30 Jun 2022 Location: Whitewright Points: 10 |
Post Options
Thanks(0)
|
I did everything recommended to me now tractor will not move in any forward gear or reverse. Guessing since mine is a series 2d17 needs gear pil80w in the dipstuck filler left front of gear shifter? Dammit spent allot of money and time doing this and have to start over in worst condition that condition that was.
|
|
DrAllis
Orange Level Access Joined: 12 Sep 2009 Points: 19478 |
Post Options
Thanks(0)
|
Tractor won't move at all?? and you have the hand clutch lever all the way FORWARD or pulled all the way to the REAR ?? You bought it as a tractor that wouldn't move ??????
|
|
Ijos27
Bronze Level Joined: 30 Jun 2022 Location: Whitewright Points: 10 |
Post Options
Thanks(0)
|
Nevermind I read up a few post and glad someone mention power director clutch! I had mine in neutral so once that got moved to low or high it moved. Thanks for everything. Atleast I know whats in the tractor now because I put it in it there. Yall be good now
|
|
