70 series planter setup
 Post Reply Post Reply
Author
Message
  Topic Search Topic Search  Topic Options Topic Options
klocke.kyle@yahoo.co View Drop Down
Bronze Level
Bronze Level
Avatar

Joined: 18 Mar 2024
Location: Batchtown
Points: 16 		Post Options Post Options   Thanks (0) Thanks(0)   Quote klocke.kyle@yahoo.co Quote  Post ReplyReply Direct Link To This Post Topic: 70 series planter setup
    Posted: 30 Mar 2024 at 8:26am
If anyone has a 70 series manual. I’d appreciate some help. My planter right now is set up on 30” rows with 24 cell sunflower plates. It has a 18 tooth drive socket and a 10 tooth driven socket. Would anyone happen to know the seed spacing I would have with this setup?
Back to Top
Sponsored Links


Back to Top
tbran View Drop Down
Orange Level
Orange Level


Joined: 14 Sep 2009
Location: Paris Tn
Points: 3482 		Post Options Post Options   Thanks (0) Thanks(0)   Quote tbran Quote  Post ReplyReply Direct Link To This Post Posted: 30 Mar 2024 at 8:52am
We lost all our manuals -but

Even though it is flat chain 74 series the charts are the same.  You could do the math - a 10/14 = 8" spacing.  A better method is to measure the OD of your drive tire - Roll it one revoution exactly - and count the seeds and divide into the circumfrence.  Kee in mind some sunflower seed plates require a filler plate as sunflower seed are half the depth of a corn kernal.
When told "it's not the money,it's the principle", remember, it's always the money..
Back to Top
jvin248 View Drop Down
Silver Level
Silver Level
Avatar

Joined: 17 Jan 2022
Location: Detroit
Points: 422 		Post Options Post Options   Thanks (0) Thanks(0)   Quote jvin248 Quote  Post ReplyReply Direct Link To This Post Posted: 30 Mar 2024 at 10:23pm
.

Old school method is drag it down the hard dirt driveway and then measure/count the seed drops.

Next best is measure the diameter of the ground wheel you have and then the teeth per gear involved. Ratio everything and there you go.

.
Back to Top
orangereborn View Drop Down
Orange Level
Orange Level
Avatar

Joined: 12 Sep 2009
Location: NW WI
Points: 1458 		Post Options Post Options   Thanks (0) Thanks(0)   Quote orangereborn Quote  Post ReplyReply Direct Link To This Post Posted: 01 Apr 2024 at 3:58pm
Back to Top
Unit3 View Drop Down
Orange Level
Orange Level
Avatar

Joined: 17 Oct 2009
Location: NC Iowa
Points: 5572 		Post Options Post Options   Thanks (0) Thanks(0)   Quote Unit3 Quote  Post ReplyReply Direct Link To This Post Posted: 01 Apr 2024 at 11:00pm
Originally posted by jvin248 jvin248 wrote:

.

Old school method is drag it down the hard dirt driveway and then measure/count the seed drops.

Next best is measure the diameter of the ground wheel you have and then the teeth per gear involved. Ratio everything and there you go.

.

Jvin248, you just brought back a memory for me of my dad and grandpa. I can hear my dad telling my grandpa it wouldn’t work. He said he couldn’t pull that planter in that hard ground. Grandpa said sure you can. I’ll even help push if I need to. Thanks for the memories.
2-8070FWA PS/8050PS/7080/7045PS/200/D15-II/2-WD45/WD/3-WC/UC/C
